High-Performance 12/20kV XLPE Insulated Power Cable for Industrial & Utility Networks (70-400mm²)
Product Introduction
Our 12/20kV (24kV) Three-Core XLPE Insulated Power Cable is engineered for reliable medium-voltage power distribution in demanding industrial and utility applications. Constructed with compact stranded copper conductors (Class 2 per IEC 60228) and insulated with superior cross-linked polyethylene (XLPE), this cable is designed for fixed installations indoors and outdoors. This robust XLPE Insulated Power Cable delivers exceptional electrical performance, thermal stability, and long-term durability, making it an ideal choice for powering critical infrastructure, including manufacturing facilities for equipment such as lipstick filling machines, across regulated markets like the EU, North America, and Southeast Asia.
Features & Benefits
-
Superior Electrical & Thermal Performance: The high-grade XLPE insulation provides excellent dielectric strength, allowing a high current rating and a maximum continuous conductor temperature of 90°C. This ensures efficient power transmission with minimal losses and enhanced overload capacity.
-
Exceptional Durability & Safety: Designed to meet international standards including IEC 60502-2 and VDE 0276, this XLPE Insulated Power Cable offers outstanding resistance to thermal aging, environmental stress, and electrical treeing. The durable PVC sheath provides robust protection against moisture, abrasion, and chemical exposure.
-
Global Compliance & Certification: Supplied with key international certifications such as CE, KEMA, and CCC, this cable is fully compliant for projects in the European Union, North America, and regions like Vietnam and Southeast Asia, ensuring hassle-free approval and installation.
-
Optimized for Critical Applications: Whether for utility substations, industrial plant mains, or large commercial power feeds, this reliable XLPE Insulated Power Cable ensures a stable and secure power supply, minimizing downtime and maintenance costs.
Why Choose Our XLPE Insulated Power Cable?
We are a professional manufacturer committed to delivering power cable solutions that combine quality, reliability, and value. Our extensive experience and strict adherence to international manufacturing standards guarantee that every meter of XLPE Insulated Power Cable meets the highest performance criteria. We provide comprehensive technical support, from specification assistance to installation guidance, and offer flexible packaging and reliable logistics to ensure your project—wherever it is located—remains on schedule. Our products are backed by robust warranties and a customer-centric service promise.
Technical Data Snapshot (Three-Core Examples)
|
Nom. Cross-Section
|
Insulation Thickness
|
Approx. Overall Diameter
|
Approx. Weight
|
Current Rating in Air
|
|
3x70 mm²
|
5.5 mm
|
63 mm
|
3321 kg/km
|
195 A
|
|
3x95 mm²
|
5.5 mm
|
67 mm
|
3825 kg/km
|
240 A
|
|
3x150 mm²
|
5.5 mm
|
74 mm
|
4846 kg/km
|
310 A
|
|
3x240 mm²
|
5.5 mm
|
84 mm
|
6263 kg/km
|
420 A
|
|
3x400 mm²
|
5.5 mm
|
96 mm
|
8647 kg/km
|
555 A
|
Key Specifications: Rated Voltage: 12/20 kV (Um: 24 kV) | Test Voltage: 42 kV AC for 5 min | Max. Operating Temp.: 90°C | Min. Bending Radius: 15 x Cable Diameter
FAQ
Q: What makes an XLPE Insulated Power Cable superior to other types for MV applications?
A: XLPE (Cross-linked Polyethylene) insulation offers significantly higher thermal resistance (up to 90°C), superior dielectric properties, and excellent resistance to moisture and environmental stress compared to traditional materials like PVC or PE. This results in a more compact, lighter, and longer-lasting cable with higher current-carrying capacity.
Q: Is this cable suitable for direct burial or installation in cable trenches in Southeast Asia's climate?
A: Yes. The XLPE Insulated Power Cable is designed for indoor and outdoor use, including burial in cable trenches or ducts. The XLPE material and PVC sheath provide strong resistance to moisture, soil chemicals, and tropical conditions, making it suitable for projects in Vietnam and across Southeast Asia.
Q: Do you provide cables with specific color coding or markings for different phases as per EU or local standards?
A: Absolutely. While standard insulation colors are available, we can customize the sheath color or print sequential meter markings and other identifiers on the cable drum according to your project specifications and local regulatory requirements (e.g., EN 50525).
Q: What is your typical lead time for an order of 3x400mm² cable destined for North America?
A: Lead times vary based on order volume and customization. However, we prioritize efficient production and logistics. Standard orders are typically ready for shipment within a competitive timeframe, packed securely on wooden reels for ocean freight, with detailed schedules provided upon order confirmation.
